High Precision CNC Slant Bed Turning and Milling Lathe Machine
Description
Product features:
1. slant type one piece casting, two axes linear guideway, suitable for high precision processing.
2. Taiwan high precision linear guideway, ensuring for stable accuracy
3. adopts Taiwan high precision spindle, Japan precisive bearing.
4. Can equipped with medium solid or medium hollow hydraulic chuck, hydraulic station and oil tank (Taiwan)
5. Can equipped with chain type auto chip conveyor
6. Can equipped with electric tool turret, hydraulic tool turret and servo tool turret.
7. GSK/ KND control system.
Product applicant:
Auto part Communication equippment automation equippment
Product details:
Product specifications:
| Item | Unit | HTC-4640 |
| Max swing over bed | mm | 460 |
| Max turning diameter on carriage | (mm) | 170 drilling/200 excircle |
| Max cutting length | (mm) | 300 |
| Spindle motor rate | (KW) | 7.5 |
| Spindle head form | A2-6/A2-6 | |
| Hydraulic chuck diameter | mm | 6”/8” |
| Spindle max rotation speed | rpm | 4500/4000 |
| Spindle hole diameter | mm | Ø56/Ø66 |
| Work piece bar diameter | mm | Ø42/Ø52 |
| X axis max travel | 210 | |
| Z axis max travel | 400 | |
| X/Z axis connection way | Direct connection | |
| X/Z axis ball screw specification | 3210/3210 | |
| X/Z axis linear guideway specification | 35/35 | |
| X/Z axis max rapid movement speed | m/min | 20/16 |
| X/Z axis rapid position accuracy | mm | 0.004/0.006 |
| Quill diameter | mm | 65 |
| Quill travel | mm | 80 |
| Tailstock max travel | mm | 300 |
| Tailstock sleeve taper hole | MT4 | |
| Tool number | 12T | |
| Tool turret center height | mm | 80 |
| Tool dimension | mm | 25 |
| Dimension (L*W*H) | mm | 2460*1615*1870 |
| Weight | Kg | 2250 |
1. GSK980TDI control system and 7.5kw GSK servo spindle motor
2. Taiwan A2-5 spindle, spindle hole 56, imported bearing and ball screw, linear guideway, 3000rpm
3. 6” Taiwan hydraulic chuck and oil cylinder, Chinese hydraulic station, imported hydraulic tailstock
4. 12 positions servo tool turret
5. Fully closed cover
6. Auto lubrication system
7. Cooling system
8. Hand unit
9. Working light
10. Manual tailstock
11. Technical documents
12. Accompanied toolbox
Optional accessories:
1. SYNTEC 22A system and servo motor, and SYNTEC matched spindle motor
2. FANUC OITF(5) system
3. 8” hollow hydraulic chuck change to 10” hollow hydraulic chuck
4. 4 positions electric tool turret
5. 8 positions Chinese servo tool turret
Main Parts Brand:
| No | Name | Plant | Original place | Note |
| 1 | Machine body | JOINT | China | |
| 2 | Control system | FANUC | Japan | |
| 3 | X/Z axis motor | SYNTEC | Taiwan | |
| 4 | X/Z axis drive | FANUC | Japan | |
| 5 | Spindle | ROYAL | Taiwan | |
| 6 | Servo spindle motor | CTB | China | |
| 7 | Ball screw | THK | Japan | |
| 8 | Linear guideway | THK | Japan | |
| 9 | Coupling | R+W | Germany | |
| 10 | Lubrication system | HERG | China and Japan venture | |
| 11 | Cooling system | ROCOI | China | |
| 12 | Transformer | FUJIE | China | |
| 13 | Main pneumatic element | AirTAC | Taiwan | |
| 14 | Main electrical element | Schneider | China and France venture | |
| 15 | DC stablized power | MW | Taiwan |
Package:
Company Information:
Shenzhen Joint Technology CO.,LTD., was established in 1995. One of our headquarters is located in PingHu town, Shenzhen City ,Guangdong province ,China, we are dedicating to research and development, production, sale, and service of mold processing machine tools and specialized machine tool equipments for machine work of excellent quality for more than two decades.
There are eight series of products-high speed turret milling machine, precision surface grinding machine, EDM machine tool, CNC milling machine, NC milling machine, Gantry type machine center, CNC engraving machine, and CNC lathe machine
Our own brand “JOINT ” Has been the top quality machine’s signal in domestic sales, JOINT also has been recognized as ” GUANGDONG Famous Brand “, and milling machine was recognized as ” TOP 10 Famous Brand of Milling machine ” in China. Our product had been exporting to Europe, South America, Southeast Asia, the middle east etc, and enjoyed a good reputation there, Welcome your visit !
