Knee-Type Milling Drilling Zx7550c Zx7550cw Drilling and Milling Machine
Model NO.
ZX7550C ZX7550CW
Automatic Grade
Semiautomatic
Precision
High Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Trademark
WELLON
Transport Package
Wood Case
Specification
1280*1100*2080mm
Origin
China
HS Code
84595900
Description
PRODUCT DESCRIPTION
Knee-Type Milling Drilling Zx7550c Zx7550cw Drilling and Milling
FEATURES:
1. Use as milling machines and drill press
2. Easily shift able gear drive ensures power transmission without losses
3. With gear spindle drive
4. Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
5. ZX7550CW with horizontal milling spindle
Technical parameters:
| Model | ZX7550C | ZX7550CW |
| Max.drilling dia (mm) | 50 | 50 |
| Max.horizontal milling dia (mm) | 100 | 100 |
| Max.vertical milling dia (mm) | 25 | 25 |
| Max.boring dia (mm) | 120 | 120 |
| Max.tapping dia | M16 | M16 |
| Distance.spindle to table surface (mm) | 50-350 | 50-350 |
| Spindle speeds range (r.p.m) | 115-1750(V) | 115-1750 (V) 60-1350(H) |
| Spindle travel | 120 | 120 |
| Table size (mm) | 1000×240 | 1000×240 |
| Table travel (mm) | 600×210 | 600×210 |
| Overall dimensions (mm) | 1280×1100×2080 | 1280×1100×2080 |
| Motor (Kw) | 0.85/1.5(V) | 0.85/1.5(V) 2.2(H) |
| N.W/G.W (Kg) | 800/950 | 850/1000 |
Standard accessories:
| Drill chuck |
| Reduction sleeve |
| Draw bar |
| X axis auto power feed |
| Mill arbors(ZX7550CW) |
| Collet chuck kits |
| Coolant system |
| Chip tray |
| Work lamp |
| Tools and box |
Optional accessories:
| Y axis power feed motor |
| Z axis power feed motor |
| 3 axis DRO |
| Air draw bar |
| Separately control panel box |
| 58 pcs Clamping kits |
| Spindle protection |
| Worktable protection |
| Worktable swivel ±45 degree |
| Rotary table HV10 |
| Dividing head BS-0 |
| Machine vice 160mm |
